Hangcha’s September X2 Series release describes two pantograph reach configurations for different rack layouts. The useful purchasing decision is not simply “double-deep or single-deep.” Buyers need to match rack depth, aisle width, pallet weight, lift height, residual capacity, travel cycle and charging access to the exact truck configuration.
Hangcha published a sequence of official X2 Series Pantograph Reach Truck updates between 15 and 23 September 2026. Together, the posts describe a double-deep configuration aimed at increasing storage density and a single-reach configuration intended for heavier pallet loads in selective racking. The manufacturer also published loaded travel and lift-speed figures and identified lithium-ion power plus an optional onboard charger.
The release is relevant to warehouse buyers because a reach truck affects the whole storage design. A wider capacity label or longer pantograph reach can look attractive in a brochure, but the practical result depends on the rack layout, pallet geometry, load centre, mast height, floor condition, turning space and the capacity that remains at the required lift height.
What the official sources state
- The double-deep version is offered in 1.4 t and 1.6 t models and has up to 1,067 mm of pantograph reach.
- The single-reach version is offered at capacities up to 2.0 t with 610 mm of pantograph reach.
- Hangcha states loaded travel speed of up to 12 km/h and loaded lift speed of up to 560 mm/s for the X2 Series.
- The range is available with lithium-ion power and can be specified with an optional onboard charger.
- Hangcha tells buyers to review aisle width, load centre, lift height and residual capacity together.
What changed
The announcement gives buyers two related product routes. One prioritises access to pallets stored two deep, where the pantograph must extend farther into the rack. The other uses a shorter pantograph reach with capacity up to 2.0 tonnes for single-deep selective storage. That distinction matters because double-deep racking can increase pallet positions but reduces direct access to the rear pallet and changes the operating cycle.
The official pages provide useful configuration-level numbers, but they do not publish a complete specification table for every mast, battery and market. A buyer should therefore treat the release as a shortlist signal and request the current data sheet for the exact quoted model.
Why rack geometry must lead the selection
Start with the warehouse, not the truck name. Record clear aisle width, rack beam height, pallet depth, pallet overhang, load centre, maximum pallet mass, floor flatness and any obstruction above the aisle. For double-deep storage, include the distance from the aisle face to the rear pallet position and the clearances around the front pallet.
Residual capacity is especially important. A nominal 1.6 t or 2.0 t rating does not mean that capacity remains available at every lift height, load centre or attachment configuration. Ask for the load chart tied to the offered mast, fork length, battery and pantograph. If the supplier cannot connect the chart to the quotation, the comparison is incomplete.
Translate speed figures into a real duty cycle
The published maximum loaded travel and lift speeds can support higher throughput, but they are not a site productivity guarantee. Throughput also depends on acceleration settings, turning, congestion, lift height, pallet alignment, operator visibility, floor condition and the time spent confirming a safe deposit or retrieval.
Provide a representative cycle: travel distance, number of turns, lift height, load mass, front or rear pallet position, shift duration and expected moves per hour. Ask the supplier to estimate energy use and productivity against that cycle, and identify which assumptions are based on calculation rather than a witnessed test.
Check charging and service before fixing the layout
Lithium-ion power and an onboard charger may simplify opportunity charging, but the electrical plan still needs confirmation. Request nominal battery voltage, usable energy, charger input, charge current, connector type, charging time, temperature limits and rules for partial charging. Confirm whether the onboard charger is standard in the destination market and whether using it changes battery size, counterweight or service access.
Service planning should include the pantograph mechanism, mast rollers, hydraulic hoses, sensors, controller, display, steering components, drive wheel and battery communications. Ask for parts numbers and expected stock locations for wear and recovery items. The ForkliftIQ parts section explains why model name alone is not enough for a replacement-parts request.
Questions to put into the RFQ
- Which X2 model and pantograph configuration fits the measured rack depth and pallet position?
- What residual capacity remains at the required lift height and load centre?
- Which mast, fork, battery and charger configuration supports the quoted performance?
- What is the right-angle stacking aisle for the exact pallet and model?
- Are the published travel and lift speeds available in the destination market and under what load conditions?
- What inspection and lubrication intervals apply to the pantograph and mast?
- Which diagnostic tools, passwords and service manuals are available to the local service team?
- Which parts are stocked locally, and what are the normal lead times for non-stock items?
How to compare the supplier response
A useful quotation should connect each claimed capability to a model code, configuration and dated technical document. It should also identify the legal entity responsible for supply, commissioning, warranty and spare parts. ForkliftIQ maintains a profile of Hangcha Group in the China supplier directory, but directory inclusion does not verify a particular dealer’s authority, stock or commercial terms.
Compare the X2 against other reach-truck candidates using the same rack drawing and duty cycle. The selection tools and buying guides can help structure the requirement before pricing is compared.
Evidence boundary
The dates, capacities, pantograph reach, speed figures and charging options in this report come from Hangcha’s official product posts. ForkliftIQ has not independently tested the X2 Series, measured residual capacity, inspected a production truck or verified regional availability. The generated editorial image above is a generic explanation of the application and is not a photograph of an X2 truck.
Primary source URLs reviewed:
https://www.hcforklift.com/talk/detail/548
https://www.hcforklift.com/talk/detail/550
https://www.hcforklift.com/talk/detail/551
