BYD ECB20 / ECB25 / ECB27

2.0–2.7 t four-wheel electric counterbalance family. Use the ECB20, ECB25 and ECB27 as three distinct load cases; the ECB27 also changes the published load-centre assumption, so capacity labels alone are not comparable.

Reviewed 2026-09-30 · manufacturer claims remain attributed · quotation-specific evidence required
Generic compact electric counterbalance forklift handling a pallet at a loading dock
Editorial equipment illustration for application orientation. It does not depict or verify a specific BYD model, option package or performance claim.
Published scope

Start with the claim, then identify the offered truck.

The facts below summarize the source reviewed by ForkliftIQ. They do not prove current availability, regional configuration or suitability for a particular site.

Published modelsECB20, ECB25 and ECB27 seated electric counterbalance trucks
Published capacities2,000 kg, 2,500 kg and 2,700 kg respectively
Published load centres500 mm for ECB20/25; 600 mm for ECB27
Published reference geometry3,000 mm standard lift and 1,195 mm overall width
Buyer interpretation

Use the ECB20, ECB25 and ECB27 as three distinct load cases; the ECB27 also changes the published load-centre assumption, so capacity labels alone are not comparable.

A model name helps organize research. Technical approval still depends on one exact configuration and a written operating requirement.

Application boundary

The manufacturer data groups three trucks in one document, but the ECB27 uses a published 600 mm load centre while the ECB20 and ECB25 use 500 mm. Compare the real load moment and residual-capacity chart rather than ranking the three capacity labels directly.

Configuration evidence

The brochure lists a 3,000 mm reference lift and 1,195 mm overall width. Mast type, lift height, fork dimensions and attachment can alter the working envelope, so the quotation needs its own dimension drawing and load chart.

Operating-system check

An electric-truck comparison also needs battery energy, charger power, connector, charging window and local service responsibility. Those items must be tied to the destination-market offer rather than inferred from a UK brochure.

Information to measure before requesting this model

Record the maximum and typical load, dimensions, load centre, pallet or attachment interface, lift height, travel route, gradients, floor and yard condition, doors, overhead restrictions, rack geometry, pedestrian interaction, temperature and expected moves per hour. Define the shifts, charging windows and electrical supply instead of asking a supplier for an undefined runtime.

For a counterbalance or heavy-duty truck, state tyre requirements, outdoor exposure, braking demand and attachment use. For a connected truck, add network boundaries, user roles, data ownership, offline behaviour and system-support expectations. These inputs let suppliers identify exclusions early.

Questions for the quotation

  • Which exact model, mast and fork or attachment combination is being offered?
  • Does the quoted load chart use the same load centre as the real load?
  • Which battery, charger, connector and destination electrical supply are included?
  • Which regional documentation, commissioning and warranty entity apply to the quotation?

Documents to request

Ask for the complete model and option codes, a dated model-specific data sheet, dimensions, the configuration-specific load chart, battery and charger data, attachment approval, tyre specification, operator and maintenance manuals, scheduled service requirements and the applicable destination-market conformity records. The contracting party should identify who commissions the truck, provides training, supports diagnostics, supplies parts and carries warranty responsibility.

How to compare an alternative

Build one comparison sheet and hold the operating case constant. Use the same load, load centre, lift height, attachment, aisle or route, gradients, floor, temperature, shifts and charging window for every candidate. Ask suppliers to show where each quoted value comes from and whether it is standard, optional, calculated, tested or dependent on a market package.

Separate truck price from the operating system around it. Include charger and electrical work, battery replacement assumptions, tyres, scheduled service, diagnostic access, software or telematics fees, training, commissioning, freight, spare parts and expected downtime support. A lower equipment price can produce a higher operational cost when these boundaries are omitted.

Commercial and delivery boundary

Record the legal seller, Incoterm, delivery location, included options, excluded installation work, document language, acceptance method, warranty start, response time and responsible service entity. Require written change control when the supplier substitutes a mast, battery, charger, tyre, controller or software package after the technical review.

Parts and service identity

The family name is not sufficient for a parts match. Preserve the data plate, full model, serial number, mast and attachment details, battery voltage, controller and display labels, old component number, connectors, ports, mounting points and dimensions. Ask the source of every proposed replacement: catalogue record, drawing, supersession notice or written manufacturer confirmation.

Evidence boundary

ForkliftIQ has not inspected or tested this truck. Published capacity, dimensions, energy and software statements remain attributed to the manufacturer source. Current availability, exact configuration, regional documentation, dealer authority, lead time, field performance and warranty must be confirmed in writing for the offered truck.

Primary manufacturer source reviewedhttps://bydforklift.com/uk/wp-content/uploads/4.5_BYD-Counterbalance-forklifts_ECB20.ECB25.ECB27.pdf
Configuration detail from the source

Separate the standard energy package from options

The reviewed BYD Europe brochure carries document code 04-22/BPS/V1. Treat the following as that brochure's published configuration, not confirmation of today's destination-market offer. Its standard-equipment list specifies an 80 V 270 Ah battery (21.6 kWh) and an 80 V 100 A charger. The optional-equipment list separately includes 80 V 340 Ah (27.2 kWh) and 80 V 540 Ah (43.2 kWh) batteries, an 80 V 200 A charger and a one-hour fast-charging solution. The brochure does not establish that every battery and charger combination delivers the same charging time.

Compare the controls and included equipment

The standard list includes dual AC drive, a four-way valve and integrated side-shifter. It distinguishes a mechanical lever on the Basic model from finger-tip control on the Comfort model. Dual joystick control, cabin and weather-protection kits, multiple mast variants and additional lighting appear in the optional list. Ask the seller to itemise the offered control package, hydraulic functions, attachment, mast and weather equipment so that a comparison does not assume options are included.

Turn the brochure into a quotation check

Request the current data sheet and full option codes for the selected ECB20, ECB25 or ECB27. Record the exact battery voltage, capacity, charger input supply and output current, connector and charging conditions. Ask which quoted items are standard, optional or excluded. For the side-shifter, obtain the capacity plate or residual-capacity chart for the offered mast and load centre rather than assuming the catalogue's headline capacity survives every configuration.

The document also advertises a battery warranty of eight years or 10,000 hours, whichever comes first. This is a published brochure claim; it does not establish the coverage, exclusions, capacity-retention threshold or responsible warranty entity for a current purchase. Obtain the applicable written warranty and identify who handles the claim in the destination country. BYD's brochure reserves the right to change features and technical parameters, making a dated quotation-specific confirmation essential.

Source: BYD Europe ECB20/25/27 brochure, document 04-22/BPS/V1; the full primary-source URL appears in the evidence section below. Reviewed by ForkliftIQ on 1 October 2026. This supplement describes published equipment lists; it is not a product test or current-stock confirmation.
