Named-model research
UN FE Three-Wheel Series
1.6–2.0 t three-wheel electric counterbalance series. Use FBT16, FBT18 and FBT20 as separate geometry and load cases; confirm the exact battery route, mast and warehouse layout instead of relying on the FE family name.
Reviewed 2026-09-30 · manufacturer claims remain attributed · quotation-specific evidence required
Published scope
Start with the claim, then identify the offered truck.
The facts below summarize the source reviewed by ForkliftIQ. They do not prove current availability, regional configuration or suitability for a particular site.
Buyer interpretation
Use FBT16, FBT18 and FBT20 as separate geometry and load cases; confirm the exact battery route, mast and warehouse layout instead of relying on the FE family name.
A model name helps organize research. Technical approval still depends on one exact configuration and a written operating requirement.
Application boundary
The three-wheel route is primarily a geometry decision. The manufacturer table separates FBT16, FBT18 and FBT20 by capacity and dimensions, so a buyer should calculate doors, turns and pallet aisles with the exact offered model.
Configuration evidence
A nominal capacity does not establish residual capacity at height. Request the load chart for the quoted mast, load centre, fork and attachment, and keep that evidence with the final configuration record.
Operating-system check
The published FE material presents more than one energy route. Battery chemistry, voltage, capacity, weight, charger and site supply must be confirmed together rather than transferred between variants.
Information to measure before requesting this model
Record the maximum and typical load, dimensions, load centre, pallet or attachment interface, lift height, travel route, gradients, floor and yard condition, doors, overhead restrictions, rack geometry, pedestrian interaction, temperature and expected moves per hour. Define the shifts, charging windows and electrical supply instead of asking a supplier for an undefined runtime.
For a counterbalance or heavy-duty truck, state tyre requirements, outdoor exposure, braking demand and attachment use. For a connected truck, add network boundaries, user roles, data ownership, offline behaviour and system-support expectations. These inputs let suppliers identify exclusions early.
Questions for the quotation
- Which FBT model, mast, fork and attachment are included in the quotation?
- Do the pallet aisle and doorway calculations use the quoted configuration?
- Which battery chemistry, voltage, capacity and charger apply to this truck?
- Which safety options, manuals, service tools and warranty route apply at the destination?
Documents to request
Ask for the complete model and option codes, a dated model-specific data sheet, dimensions, the configuration-specific load chart, battery and charger data, attachment approval, tyre specification, operator and maintenance manuals, scheduled service requirements and the applicable destination-market conformity records. The contracting party should identify who commissions the truck, provides training, supports diagnostics, supplies parts and carries warranty responsibility.
How to compare an alternative
Build one comparison sheet and hold the operating case constant. Use the same load, load centre, lift height, attachment, aisle or route, gradients, floor, temperature, shifts and charging window for every candidate. Ask suppliers to show where each quoted value comes from and whether it is standard, optional, calculated, tested or dependent on a market package.
Separate truck price from the operating system around it. Include charger and electrical work, battery replacement assumptions, tyres, scheduled service, diagnostic access, software or telematics fees, training, commissioning, freight, spare parts and expected downtime support. A lower equipment price can produce a higher operational cost when these boundaries are omitted.
Commercial and delivery boundary
Record the legal seller, Incoterm, delivery location, included options, excluded installation work, document language, acceptance method, warranty start, response time and responsible service entity. Require written change control when the supplier substitutes a mast, battery, charger, tyre, controller or software package after the technical review.
Parts and service identity
The family name is not sufficient for a parts match. Preserve the data plate, full model, serial number, mast and attachment details, battery voltage, controller and display labels, old component number, connectors, ports, mounting points and dimensions. Ask the source of every proposed replacement: catalogue record, drawing, supersession notice or written manufacturer confirmation.
Evidence boundary
ForkliftIQ has not inspected or tested this truck. Published capacity, dimensions, energy and software statements remain attributed to the manufacturer source. Current availability, exact configuration, regional documentation, dealer authority, lead time, field performance and warranty must be confirmed in writing for the offered truck.
Primary manufacturer source reviewed
https://www.unforklift.com/product/three-wheel-electric-1-6t2-0t/fe-series-1-62-0t.htmlConfiguration detail from the source
Keep the pallet orientation with the FE aisle dimension
The detailed manufacturer table lists 3,261 mm aisle width for FBT16/18 with 1,000 × 1,200 mm pallets crossways, and 3,386 mm with 800 × 1,200 mm pallets lengthways. FBT20 has corresponding entries of 3,351 and 3,476 mm. Those pallet dimensions and orientations belong with the quoted aisle number; they are not interchangeable clearances.
Body length without forks is 1,930 mm for FBT16/18 and 2,025 mm for FBT20. Request the complete envelope with the supplied forks, mast and load when checking a door or transfer route. The source presents both 48 V battery entries and 77.28 V / 150 Ah entries. Confirm the exact electrical package, battery weight and charger rather than treating those alternatives as interchangeable replacements.
Evidence: UN FE Three-Wheel Series manufacturer source, reviewed 1 October 2026; the full URL is retained in the primary-source section. Published references require confirmation for the exact destination-market configuration.
