Counterbalance Electric Stacker — CDDK15
Counterbalance Electric Stacker, 1,500 kg capacity — presented as a reference for a written supplier inquiry. Indicative, customizable specifications.
At a glance
These are reference values, not specifications assigned to the linked supplier. Require the actual offered model and supporting documents.
Full specifications
| Rated capacity | 1500 kg |
| Max lift height | 3000 mm — customizable |
| Type | Counterbalanced (straddle-free, enters closed pallets) |
| Drive | AC electric |
| Fork length | 1150 mm |
| Battery | 24V (indicative) |
Key features
Lift to height
Vertical mast lifts pallets onto racking and mezzanines.
Walk-behind compact
Tiller-controlled walkie design needs little aisle space.
Electric drive & lift
Clean, quiet indoor operation with smooth proportional lift.
Customizable mast
Single, two- or three-stage masts and fork lengths to suit your racking.
Questions before a CDDK15 inquiry
What should I include in a CDDK15 inquiry?
Send pallet dimensions and orientation, fork-entry information, load details, lift height and access measurements. Request a configuration drawing before assuming pallet compatibility.
Which specifications should I confirm before ordering?
Request the manufacturer and complete model designation, data sheet, mast and dimension drawings, applicable capacity documentation, and battery and charger details. The existing numerical listings are indicative and have not been verified in this FAQ correction; they are not approval for your load or layout.
Are order quantity, availability and delivery confirmed?
No minimum order quantity, stock status, price advantage or delivery period is confirmed by this FAQ. Request a dated offer identifying the exact equipment, quantity, included items and delivery terms.
Request a quote on the CDDK15
Tell us your load, working height and destination port — use those details to request a comparable written offer.
Get my quoteCounterbalanced stacker supplier research
NOBLELIFT lists PS12/16/18CB as an electric counterweight stacker family, with nominal capacities of 1.2, 1.6 and 1.8 tonnes.
Scope of this link: This is a layout-family comparison, not an exact 1.5-tonne match. CDDK15 is the page reference, not a confirmed NOBLELIFT designation. The source does not establish pallet entry, aisle suitability, residual capacity or the mast and battery values elsewhere on this page.
Prepare the pallet and rack requirement
Provide pallet dimensions, bottom-board layout and fork-entry direction, load dimensions and centre of gravity, rack beam height, door clearance and measured aisle space. Separate nominal capacity from the capacity chart for the proposed lift height, mast and load centre. Ask for a chassis drawing showing the fork and support-leg arrangement; a similar category name does not establish access to a closed pallet.
List travel distance, work frequency, floors and charging arrangements. Require the offer to identify powered travel, powered lift and any manual functions, together with the exact battery, charger, included accessories and commissioning scope. Compare the technical response before price and record unresolved dimensions instead of assuming the reference values apply.
