XILIN CSD16 / CSD20 four-way forklifts

What the official reference establishes

The official CSD16.20 page describes battery-powered four-way forklifts able to travel longitudinally and laterally. It attributes the movement arrangement to twin drives and twin steering systems. The dedicated photograph shows an open seated truck with an overhead guard, mast and two forks. This is a distinct handling role from existing XILIN reach-truck, pallet-truck and order-picker references; similar mast appearance does not make those models interchangeable.

Keep the reference and interfaces together

The main technical table lists CSD16 and CSD20 nominal capacities of 1600 and 2000 kg respectively, at a 500 mm load centre. It lists lift heights of 3000, 3500, 4000, 5000 and 6200 mm as configuration alternatives. A separate elevated-capacity table shows 1600, 1350, 1200, 950 and 700 kg against those heights for BOTH model labels. In particular, its CSD20 row begins at 1600 kg despite the main table’s 2000 kg nominal entry. This apparent mismatch is preserved; no invented correction or full-height 2000 kg capacity is asserted.

Keep the supply package explicit

Use the load dimensions, actual load centre, lateral handling requirement and selected mast to request a current residual-capacity chart. The main table shows a common 48 V / 490 Ah electrical entry, but it does not establish the supplied battery chemistry, charger or endurance. Confirm the offered mast, forks, battery, steering configuration and workplace clearances in controlled documentation. Energy-saving, maintenance-free, zero-pollution and safe-handling claims are not adopted as independently verified performance.

Questions for the proposed product

What belongs in the requirement?

Give the full proposed model and revision, load dimensions and mass, operating route, quantity and destination. Describe the task and site constraints before comparing quotations. A catalogue image does not establish the equipment configuration or suitability.

Which current documents are needed?

Request a configuration-specific datasheet, applicable operating manual, load or towing limits and matched battery/charger information. Have the responsible supplier assess the actual workplace and duty. Keep discrepancies between web text and tables open until documented.

What should the written offer identify?

Confirm the quoting company, exact machine, condition and origin, included battery, charger and accessories, delivery terms, warranty and acceptance documents. Existing contact and purchasing links are preparation routes; clicking them is not a completed or qualified enquiry.

From product research to a comparable request

Prepare a written requirement with the duty or installed component identity, current drawings or part records, quantity, destination and requested supply scope. Compare the exact proposed configuration or component and keep unresolved differences visible. Existing supplier and purchasing tools remain below; following a link does not itself send an enquiry.

Sources and evidence boundary

The official About and Contact pages identify Ningbo Ruyi and the XILIN brand at No. 656 Taoyuan North Road, Ninghai, Ningbo. Four detail bodies, photographs and technical images were read. Separate model columns and measurement labels are retained. QDD electrical/braking descriptions differ between prose and table; CSD20 nominal and elevated-capacity entries do not agree. Current documents must resolve those limits before selection. Company awards, patents, market share, maintenance claims, certification and workplace suitability are not independently audited. Illustrations explain visible family form, not stock or an approved configuration.
