Minglong HELI QYD LF2 / LG2 standing tow tractors

What the official reference establishes

Minglong lists four standing electric tow-tractor models in one table: QYD20S-LF2, QYD30S-LF2, QYD30S-LG2 and QYD45S-LF2. The corresponding rated towing-weight entries are 2000, 3000, 3000 and 4500 kg. These are supplier catalogue towing figures, not platform payloads, fork capacities or independently measured results. The photograph presents the open standing platform, padded rear support and tiller-style front controls; it does not identify every suffix separately.

Keep the reference and interfaces together

The steering row assigns electric steering to the LF2 columns and mechanical steering to QYD30S-LG2. The two 3000 kg entries therefore remain distinct model configurations within one family. All four columns show 1490 mm length, 754 mm width and 1200 mm overall height, while drive-motor entries are 1.5 kW for QYD20S-LF2 and 2.6 kW for the other three. Request a current drawing and exact offered steering arrangement instead of treating the similarly named trucks as interchangeable.

Keep the supply package explicit

Prepare the trailer train, hitch geometry, gross towed mass, route, stopping and turning requirements for supplier assessment. The narrative describes AC drive, braking features and battery extraction alternatives, but its efficiency, reliability and safety language is not adopted as an independent guarantee. The table does not establish the current battery, charger, duty endurance or approved trailer package. Do not use this page as a coupling or operating procedure.

Questions for the proposed product

What should the requirement identify?

Record the exact complete model code, operating position, goods or trailer gross mass, load distribution, route, gradients, surface, turning space, duty, quantity and destination. A towing figure is not a platform payload or a forklift lifting capacity. Ask for an application assessment against the actual route.

Which documents should support the offer?

Request the current manufacturer datasheet, drawing, declared capacity basis, electrical and charging equipment, operating manual and configuration list. Keep optional equipment, undocumented alternatives and missing revisions visible in the supplier response. No equipment is approved for a particular site by this reference.

How should the commercial scope be compared?

Confirm the legal entity issuing the offer and invoice, condition, exact configuration, included accessories, inspection documents, delivery terms, lead time, warranty and support route. A catalogue entry is not a current stock promise. Existing procurement tools prepare a requirement; a link click is not an effective enquiry or order.

From product research to a comparable request

Prepare a written requirement with the duty or installed component identity, current drawings or part records, quantity, destination and requested supply scope. Compare the exact proposed configuration or component and keep unresolved differences visible. Existing supplier and purchasing tools remain below; following a link does not itself send an enquiry.

Sources and evidence boundary

The company website identifies Minglong and publishes Quzhou, Longyou and Lanxi contact routes. This is the same catalogue used by the existing Lanxi supplier record; its warehouse references remain linked rather than duplicated. Four towing and fixed-platform product bodies, complete tables and original images were read. Figures are attributed supplier catalogue entries. Current authorization, legal registration, branch stock, battery and charger packages, test results and application suitability are not independently verified. Keep complete model suffixes and unresolved options in a written offer. Illustrations explain family form and do not prove stock, dimensions or a delivered configuration.

https://www.qzmljx.com/cnlist_941.html

https://35js.qiyunnet.com/qzmljx/qiyunnet/af280afd508dd8c2a61973fe1b818225.png

https://www.qzmljx.com/cn_27.html

https://www.qzmljx.com/cn_6.html
