Anqing Heli AQ-L02A7-10000 tow-tractor drive axle

What the official reference establishes

The official drive-axle catalogue has a dedicated entry and photograph for AQ-L02A7-10000, described as a “2.5t tow-tractor drive axle assembly” and dated 29 May 2025. The inspected detail does not define the basis of that 2.5t label. It must not be converted into an approved towed-train mass, drawbar force, axle loading or gradient capability. A current vehicle and application document is needed to establish those separate quantities.

Keep the reference and interfaces together

The source photograph depicts a broad assembly with a rounded centre housing, end hubs and visible peripheral components. This is a different catalogue reference from the supplier’s rough-terrain forklift drive axle. Neither a similar hub form nor a tow-tractor category establishes common ratios, splines, brake controls or mounting geometry. The illustration is a presentation of the photographed external form, not a parts diagram or a complete statement of included supply.

Keep the supply package explicit

Prepare the tractor and axle nameplates, serial and revision information, wheel and mounting records, input/motor connection details and actual duty. Request the current ratio, load basis, hub and braking schedule and approved application documents. Separate the axle assembly from the motor, controller, tyres and service parts in the quotation. No hitching, towing, brake adjustment or replacement procedure is provided here; current stock, fit and supply scope require written confirmation.

Questions for the proposed product

Which identity should the request preserve?

Send the complete truck and assembly nameplates, full part number and suffix, revision or serial range, quantity, destination and required supply scope. Keep the installed assembly photographs and available parts records together. A similar housing or tonnage label cannot establish a replacement match.

Which interfaces need written confirmation?

Request a current controlled drawing, dimensional and mounting schedule, mating-component details and the supplier’s matching basis for the actual vehicle. Ask who approves the application and what documents define the supplied assembly and exclusions. Do not use an illustration as a measuring or installation guide.

What should the quotation state?

Confirm the legal quoting entity, exact assembly code and revision, included motor, wheel, brakes, actuator or service items where applicable, current documentation, condition, delivery, warranty and exclusions. Existing purchasing links prepare a requirement; following one does not send or prove a valid enquiry.

From product research to a comparable request

Prepare a written requirement with the duty or installed component identity, current drawings or part records, quantity, destination and requested supply scope. Compare the exact proposed configuration or component and keep unresolved differences visible. Existing supplier and purchasing tools remain below; following a link does not itself send an enquiry.

Sources and evidence boundary

The HELI-hosted company introduction names Anqing Heli Axle and states its affiliation to Anhui Heli. Four official product-detail bodies dated 29 May 2025 and their individually mapped original photographs establish catalogue identifiers and product forms. They do not supply controlled engineering drawings or numeric application specifications. The existing drivetrain identification guide already mentions two of these codes and remains linked and unchanged. Title tonnage, visual resemblance and shared catalogue categories do not establish load ratings, fit, matched sets, stock or included supply. Current technical and commercial documents must define the proposed assembly.
