PPT heavy electric pallet truck family

What the official product catalogue establishes

This Chungyun catalogue entry is specifically headed PPT-80/100/150 heavy electric pallet trucks. Its parameter image lists rated loads of 8,000, 10,000 and 15,000 kg for the three alternatives. The equipment picture shows a substantial power unit, standing operator area, overhead frame and long low forks. It is a different enquiry from the ordinary PPT pallet-truck family elsewhere in the same catalogue. We therefore keep the heavy series on one distinct page, grouping its capacity alternatives while preserving their different ratings. Neither the name nor the picture establishes a particular truck’s present condition or availability.

Define the work before choosing a configuration

Heavy low-lift carrying depends on the interface between the load support and the forks. Establish the skid or pallet construction, openings, load distribution, centre of gravity and required ground clearance before treating a headline rating as sufficient. The supplier table shows fork dimensions of 2,350 by 1,400 mm and notes customisation; this should prompt a drawing request rather than an assumption that the dimensions suit every listed variant or load. It also prints two lift-range alternatives, 120–240 mm and 180–270 mm. Their allocation to the offered configuration is not resolved here. These are low-lift carrying references, not high-rack stacking specifications.

Keep the supply package explicit

Request a model-specific dimension and capacity sheet, wheel-loading information for site review, battery and charger details, and the actual operator-compartment arrangement. Separate payload from drawbar pull or trailer mass: this entry’s listed tonnes are carrying ratings and are not evidence of towing capability. The table includes battery and charger descriptions, but its charger wording does not provide an independently checked electrical connection requirement. Confirm the proposed charger’s nameplate and destination supply with the responsible technical parties. Any platform conversion, special forks or other custom load interface should be itemised as a separate configuration decision.

Questions for the proposed product

Is PPT-150 simply a normal pallet truck with a larger rating?

The source presents it in a heavy family with different proportions and support requirements. Do not transfer ordinary PPT dimensions or assumptions to this enquiry.

Can the 8–15 tonne figures be used as trailer capacities?

No. They are source-listed carried loads, not verified drawbar or train ratings. A towing requirement needs its own documented equipment selection.

Which fork length and lift range will be supplied?

The source shows dimensions and alternatives but does not establish your offer. Ask for a current drawing identifying the exact model and every selected option.

From product research to a comparable request

Prepare a written requirement with the load, load centre, handling height, support dimensions, site interfaces, operating conditions, destination and quantity. Ask each shortlisted supplier to answer the same requirement and identify assumptions or exclusions. Keep the proposed equipment or attachment, accessories, documentation, delivery and support scope visible as separate lines. An equivalent headline capacity does not by itself make two offers comparable.

Sources and evidence boundary

The source is Kunshan Chungyun’s own sales catalogue. The source catalogue entry is dated 29 April 2019; this historical listing is not evidence of a current offer or a new launch. The review date is not a release date. The company is a sales and service supplier; inclusion does not establish manufacturer identity or brand authorization. It establishes published product-family presentation, not local stock, a confirmed delivery date, a specific quotation, export coverage or a technical approval. Manufacturer benefits and safety, performance, emissions, certification and savings claims have not been independently verified here. Request current exact-model documentation and appropriate technical review for the actual transaction. This is selection and procurement research, not operating or repair guidance.
