Shanye SYG-Q mini manual stacker family

What the official reference establishes

The official SYG-Q page groups SYG-Q 0411, 0413 and 0415. Its table gives nominal 400 kg load at 350 mm load centre for each, with maximum fork heights of 1100, 1300 and 1500 mm respectively. The stated operation is walking and the lift method is foot-operated. These variants stay on one family reference page; their height suffixes are not treated as three unrelated products.

Define the work before choosing a configuration

The supplier describes an optional platform board measuring 610×580 mm and shows that board in the original photograph. The presentation on this page retains that illustrated option. Its presence does not mean a quoted stacker includes the board. Confirm whether the request is for forks, a platform or both, and request the exact support-leg and carriage drawings. The source also offers custom support-leg and fork dimensions; those possibilities do not establish an approved custom configuration.

Keep the supply package explicit

The table lists 550 mm fork outer width and 615 mm working length for the shown variants, but an offered customised machine needs its own documentation. Keep load centre, lift height, load distribution, support geometry and permitted use together for supplier review. Broad claims about comfort, imported materials or turning performance are not independently verified here. No stability, personnel lifting, installation or operating approval is inferred from the photograph.

Questions for the proposed product

Which complete configuration is proposed?

State the exact series, suffix, load and height variant, fork and support geometry, wheels, controls and included accessories. Supply the current drawing and datasheet for the quoted assembly.

What establishes the application match?

Provide the actual load and pallet information, requested height, travel route and site constraints. Require the responsible supplier to confirm the proposed configuration and applicable capacity and use documentation.

What is included in the supply package?

Confirm current availability, lead time, contracting entity, warranty and required documents. Clarify every optional accessory; powered products also need a matched battery and charger specification. No stock, authorization or certification is assumed from a website listing.

From product research to a comparable request

Prepare one written handling requirement around the actual load, pallet or drum identity, required heights, aisle and floor limits, energy source and documentation. Compare the complete offered configuration and keep unresolved differences visible. Existing supplier and purchasing tools remain below; following a link does not itself send an enquiry.

Sources and evidence boundary

The current company-controlled website header and footer identify Zhejiang Lanxi Shanye Machinery Co., Ltd. and publish Xiangxi Industrial Zone, Lanxi, Zhejiang. The contact body and four individual product bodies, parameter tables and original images were read in a normal browser; direct request-client403 responses are recorded as an access limitation, not product evidence. Company identity is website-supported, not a legal-registration or factory audit. Publication dates are not stated for the selected products, and photo-path dates do not prove current specifications. Confirm the current contracting entity, exact configuration and written documents. No stock, authorization, certification, safety or fitment promise is made. Images explain equipment form, not performance or a supplied assembly.

https://www.chinashanye.com/product/manual-stacker-series/sygq-mini-hand-stacker.html

https://www.chinashanye.com/shanyelift/2023/01/04/_0002_q.png

https://www.chinashanye.com/contact/
