Longhe K-series sideshifting fork positioner

What the official reference establishes

The current Longhe product page identifies the K-series as a hydraulic fork positioner with sideshift. These are two different movements: changing the spacing between forks answers the pallet entry geometry, while sideshift changes lateral position. Neither function turns the attachment into a load clamp. The manufacturer drawing groups TJC45K, TJC68K and TJC80K codes under this family; width and mounting suffixes remain part of the complete order reference.

Define the work before choosing a configuration

The K-series drawing shows carriage widths and opening ranges as separate fields. Its note defines opening range between the outer fork edges, which a buyer should distinguish from the clear opening or the pallet pocket centres. The same drawing identifies the backrest and forks as optional, with the wording to be clarified in the actual offer. Our pale backrest outline is illustrative; it does not mean that item is included. Do not replace these K codes with M, F or E family data from older category pages.

Keep the supply package explicit

Prepare the truck make, model, serial number, carriage class and usable width, existing forks, pallet entry dimensions and intended loads. Request the current complete assembly drawing, fork pocket details and a list of included items. Attachment table figures do not establish the residual capacity of a particular truck combination. Have the responsible manufacturer or competent party confirm the proposed combination and its documents before purchase or use.

Questions for the proposed product

Which complete TJC code is offered?

Keep the capacity-family prefix, mounting and width suffix together in the quotation and drawing. A K-series label alone is insufficient to identify mounting or spare parts.

Are forks and the backrest included?

Ask for an itemised package. The source drawing labels them optional; confirm whether existing forks are proposed, and which identity and dimensions support that proposal.

How are the two hydraulic functions documented?

Request the current circuit and interface requirements for the offered assembly, including the control arrangement. This reference supplies no installation or hydraulic adjustment procedure.

From product research to a comparable request

Prepare a written attachment requirement around the actual load, working envelope, route and duty pattern. Request a full series/model designation and current configuration documents. Compare the attachment, carriage interface, hydraulic functions, forks or arms, accessories, documentation, delivery and support separately. A shared short code, similar appearance or catalogue capacity class does not establish that two offers are equivalent.

Sources and evidence boundary

The current company-controlled Longhe website identifies Longhe Intelligent Equipment Manufacturing Co., Ltd. in Longyan High-tech Zone, Fujian, consistent with this supplier record. The redesigned product pages and their mapped images were read directly. Legacy product URLs now redirect to the homepage; their old tables are not silently reused. The current product pages are undated, and image upload paths are not launch dates. These sources establish published identity and product scope, not independently tested performance. Drawings and illustrations do not establish exact supplied geometry, stock, authorization, certification, safety or compatibility. Obtain the current model documents and written selection basis for the proposed attachment and truck combination. This is purchasing preparation, not installation, hydraulic adjustment, operating or return-to-service instruction.

https://www.longheglobal.com/Introduction.html

https://www.longheglobal.com/attachment.html

https://www.longheglobal.com/product/Sideshifting-Fork-Positioner-K-Series.html
